What is the flat head screwdriver

A “slotted flat blade screwdriver” is a long standard hand-tool dating back to the 1500s. It has a flat-bladed tip used to turn, fasten or loosen screws and bolts. The flat blade screwdriver is an extremely versatile tool and is used for fasteners of all sizes, providing significant leverage.

What is a flathead screw called?

Flat Head Screws, also called Countersunk Screws, are conical with a flat outer face and a tapering inner face. An advantage to this type of screw is that very little of the head protrudes beyond the surface, allowing it to sink into the material.

What are flat head screws used for?

This screw is more commonly used with machinery, but you will usually find flat-head screws holding book shelf and lighting tracts to the wall or ceiling. They are also used in lighting fixtures and electrical outlets as well as holding hand rails, towel racks and toilet paper holders to the wall.

How do you use a flat head screwdriver?

Hold the tip of the screwdriver with one hand as you turn its handle with the other. Grasp the handle with your dominant hand and the tip with your other as close to the head of the screw as you can. Apply enough force to turn the screwdriver clockwise to tighten the screw and the opposite direction to loosen it.

Why is it called a flat head screwdriver?

It’s known as standard because it was the original form of driver head. A flathead would refer to the geometry of a screw head itself, and a flatheaded screw could actually have any type of driving head on it (slotted, Phillips, square, etc.).

What is the purpose of a Phillips screwdriver?

Phillips screw heads allow a tighter fit than a flat head screw, which is why most factories and handymen use them. The screws tend to be lightweight and relatively small. The trick is to match your screwdriver to the type and size of screws you’re using.

What is the difference between flat head screwdriver and phillips head screwdriver?

A flathead has a single blade, and a Phillips has two blades in the shape of a cross. Attempts to use a flathead tool on a screw designed for a Phillips usually won’t be successful, and a Phillips screwdriver could never be used on a slotted screw. … The flathead has been in use far longer than the Phillips.

What are the different types of screwdriver heads?

• Types of Screwdriver.
• Flat Head (or Slotted Head) Screwdriver.
• Phillips Screwdriver.
• Pozidriv Screwdriver.
• Robertson or Square Screwdriver.
• Torx Screwdriver.
• Hex Screwdriver or Hexagon Screwdriver.

Who invented the flat head screwdriver?

Henry Frank Phillips (June 4, 1889 – April 13, 1958) was an American businessman from Portland, Oregon. The Phillips-head (“crosshead”) screw and screwdriver are named after him.

What does a Panhead screw look like?

Pan head screws take their name from the appearance of their head, which looks similar to an upside-down frying pan. … The socket is typically a slot, particularly for wood and self-tapping screws. Hexagon sockets are also common for machine screws.

Article first time published on

What's the difference between a flat head and round head screw?

The round-head screw protrudes above the surface in a half-circle. The flat-head screw is flush with the surface. Type basic types of screwdrivers are needed for driving the different types of screws. … This chart is designed for flat-head screws but can be used for any type.

Which screwdriver is used for driving star headed screw?

Torx or Star Screwdriver Torx is the trademark for a type of screw head with a six-point star-shaped intrusion, hence the generic name star screwdriver.

What are Phillips screws?

: a type of screw that has a slot in its top that looks like a cross.

Why do electricians use flat head screws?

Originally posted by JasonF: Flat head screws are good for wood as they prevent overtightening and thus help prevent stripping.

Why are there Phillips and flat head screws?

The reason for the different styles is cost and torque. Phillips screws are self-centering, making powered screwdrivers possible. They’re somewhat more expensive to produce than slotted-head. They tend to ‘cam-out’ easily under torque, making it hard to apply much torque.

What are Torx screws?

A Torx screw is a type of screw characterized by a six-lobed, star-patterned screw drive. … Torx is available as an internal and external drive although it is most commonly used as a socket within the head (internal). Torx screws were invented in 1967, by Camcar Textron, as an improvement on contemporary drive types.

When did they stop using flat head screws in furniture?

Originally screws were flat bottomed until it was realized that a pointed screw was better, just like our modern screws. After about 1850, all screws have been basically the same through today. If you find an old screw in a piece of furniture it may not be the original. One clue is to look at the slot in the head.

Why is it called a Robertson screwdriver?

He was demonstrating a spring-loaded screwdriver when the blade slipped from the screw-slot and badly cut his hand. The incident inspired him, so he decided to invent an improved and safer screw – The Robertson® Drive. P.L Robertson always looked for a better way of doing things and enjoyed working on new innovations.

When did cross head screws come out?

To counteract these disadvantages, J. P. Thompson patented a screw with a cross recess in 1933. He sold the patent to the Phillips Screw Company. It improved the profile and introduced the screw to the market in 1936/37.

What are the 3 types of screwdriver?

• Power Screwdriver. The power screwdriver is the most heavy-duty of tools available. …
• Interchangeable Head. …
• Flat-head Screwdriver. …
• Phillips Screwdriver. …
• Allen Key Screwdriver. …
• Sources:

What is the name of the star screwdriver?

Called Torx, 6 point, and star, Torx are a 6 pointed star shaped screwdriver. Originally designed in the 60’s to outperform hex screws, Torx is a trademarked name for a screwdriver that fits Torx screws, commonly seen in sizes Torx 6 to Torx 40 (or T6 to T40).

Why is there different screw heads?

Answer: The primary reason for the wide variety of screw head drive types is to ensure the fact that you will never have the proper screwdriver close at hand when you need it.

Is pan head and flat head the same?

Pan head machine screws are machine screws with heads that are flat on top and rounded on the sides. They’re similar to oval head machine screws, which also have rounded sides; the difference is that oval head screws have a rounded top, too, as opposed to a flat top, and they have tapered bases.

What is the difference between a 1 and a 2 Phillips screwdriver?

The most common sizes are #2 and #1, #2 for standard screw sizes, #1 for “miniature”. … Phillips head screwdrivers are designed to “cam out”, which means they are designed to slip out of the screw, so you don’t over-tighten them.

What does a Robertson screwdriver look like?

A Robertson screw, also known as a square or Scrulox screw drive, is specified as ANSI Type III Square Center and has a square-shaped socket in the screw head and a square protrusion on the tool. Both the tool and the socket have a slight taper.

What is a Roberts head screwdriver?

Robertson screwdriver (plural Robertson screwdrivers) (chiefly Canada) A type of screwdriver having a square tip, designed to drive a Robertson screw.

What happened to screw if you over tighten them with a screwdriver?

Screws can become stripped if you over-tighten them with a screwdriver. A stripped screw, as shown in Figure 2, may get stuck in the screw hole, or it may not tighten firmly.

Why are there no Robertson screws in America?

Most historians attribute its lack of popularity in the United States to Henry Ford. Having been nearly bankrupted by shady European licensees, Robertson refused to license his invention to Ford. Without a guaranteed supply, Ford turned to the Phillips-head screw, cementing its reign in American industry.
